Networking Concepts and Protocols

by

This blog post contains the Networking Concepts and Protocols course that can be enrolled in Pluralsight. Feel free to skim this outline to get a high-level overview of the topics that were discussed on the course.

Introduction

  • What is networking?
  • Concepts
  • Modeling network communication

Data Networking

  • Data moving from a device to another device

Understanding Data Networking

  • protocols to protocols

Modeling Systems

    • Concept
    • Language
    • Link
    • Physical

The OSI Model

  • Open Systems Interconnect

Physical Layer (Layer 1)

  • Physical Devices
  • Cables
    • Twisted Pair
    • CoAx
    • Fiber Optics
    • Copper

Data Link Layer (Layer 2)

  • Ethernet
  • DOCSIS-3 (ISP to Internet)
  • Move data from one device to another device

Network Layer (Layer 3)

  • IP Addressing
  • IP Routing

Transport Layer (Layer 4)

  • Session between client and server
  • TCP – Transmission Control Protocol
  • UDP – User Diagram Protocol

Session Layer (Layer 5)

Presentation Layer (Layer 6)

  • Decoding ASCII
  • EBCDIC (IBM Encoding)

Application Layer (Layer 7)

  • HTTP
  • HTTPS

Protocols and Port Numbers

Application Layer Protocols (Layer 7)

  • Transferring Data
  • Hypertext Transfer Protocols
    • HTTP (Layer 4 port: 80)
    • HTTPS (Layer 4 port: 443)
  • File Transfer Protocols
    • FTP (Port 20)
    • sFTP (Port 22)
      • FTP over SSH
    • TrivialFTP (Port 69)
      • Used to transfer files without authentication
    • SMB (Port 445)
  • Email Protocols
    • SMTP (Port 25/465/587)
      • Used for outbound emails
    • POP3 (Port 110/995) /IMAP (Port 143/993)
      • Used for inbound emails
  • Authentication Protocols
    • LDAP (Port 389)
    • LDAPs (Port 636)
  • Network Services
    • DHCP
    • DNS
    • NTP
  • Network Management
    • Telnet
    • SSH
    • SNMP
    • RDP
  • Audio/Video Protocols
    • H.323
    • 1720
    • SIP

Transport Layer Protocols (Layer 4)

  • TCP
    • Transmission Control Protocol
    • Uses 3-way handshake to establish session with other devices
      • SYN – SYN/ACK – ACK
    • Uses 4-way disconnect to end established session with other devices
      • FIN – FIN/ACK – FIN – FIN/ACK
      • RST
        • Immediately end established session
  • UDP
    • User Diagram Protocol
    • Only sent packets without any sequence
    • Does not establish session

Transport Layer Addressing

  • Port Numbers
  • Server Port Numbers (Registered/Well known)
    • Registered – 0-1023
    • Well Known – 1024 – 49151
  • Client Port Numbers (Temporary)
    • 49152 – 61535

Binary and Hexadecimal

  • Base 2 (0 – 1)
  • Base 10 (0 – 9)
  • Base 16 (0 – 15) (0 – F)

Introduction to IP Addressing

  • Classful
  • Classless
  • What is an IP address?
    • [ 192.168.1 ] – Network Portion [ .1 ] – Host Portion
  • Classless Addressing
    • Subnet Mask
      • Network portion where all bits are filled
  • Classful Addressing
    • Unicast
      • Class A
      • Class B
      • Class C
    • Multicast
      • Class D
  • Address Types
    • IP Address Types
      • Network Address
        • Identifier for a group of devices
      • Broadcast Address
        • Identifier for all devices on a network
      • Host Address
        • Identifies unique device on a network
    • Network Address
    • CIDR Notation
      • Example: 10.1.1.0/24
  • Subnetting Networks
    • Variable Length Subnet Masking
  • Introduction to IPV6
    • 128 bits long
    • 32 nibbles
    • 8 hextets
    • Network Portion = 64 bits
    • Interface Identifier = 64 bits
    • Leading 0’s = ::
    • 2^64 available hosts
    • Additional Details
      • Dual Stack
      • Unicast Address
      • fe80 = Link Local Address
    • IPV6 Address Acquisition
      • SLAAC
        • Windows
          • Random 64 bit Interface Identifier
        • Unix
          • Modified EUI-64
            • Get MAC Address
            • Break into half
            • add ff:fe in the middle
            • flip 7th bit on the first 8 bits
      • Neighbor Advertisement
    • IPV6 Tunneling
      • Local router creates a tunnel to the IPv6 router to acquire IPv6 address to access resources.

Ethernet and Switching

  • Layer 2 allows traffic between devices
  • Carrier Sense Multiple Access with Collision Detection (CSMA/CD)
    • Collision Domain
  • Duplex and speed
    • Half Duplex – one device communicates at a time
      • Walkietalkie
    • Full Duplex – simultaneous communication between devices
      • Telephone
  • Modern Collision Domain
  • Ethernet Speed
    • GigabitEthernet speeds require full duplex
  • Ethernet II Frame
    • Destination MAC Address (48 bits)
    • Source MAC Address (48 bits)
    • Type (16 bits)
    • Data (1500 bytes)
    • FCS (32 bits)
  • Protocol Data Unit (PDU) – Whole header

Network Topologies

  • BUS
  • Ring
  • Start

Switch

  • MAC Address Table
  • Broadcast
    • Layer 2 Broadcast address
      • Destination MAC address is all FFF…
    • Broadcast domain – group of devices on a local area network
  • Features
    • Broadcast storms prevention
    • VLANs
    • Mirroring switch ports
  • Connecting Switches
    • Broadcast Messages
    • Broadcast Storm
    • Spanning Tree Protocols
      • Shuts down redundancy
  • VLANs (Broadcast Domain)
    • Trunk Link – connects switches that are using VLNS
    • Adds additional details pointing to destination VLAN
    • Also called as Tagged Ports
    • Trunklinks/Access links
  • Switch Port Mirroring
    • Collects traffic to analyze problems within network
    • Mirror the traffic of any port that we want

Power over Ethernet (POE)

  • Gives power to connected devices

IP Routing

  • Routers
    • 2 Interfaces to operate
      • Has unique IP Network
    • IP Packet
IP Packet
    • ARP (Layer 2 Protocol)
      • Retrieves layer 2 address using layer 3 address
      • Device maintains an ARP cache
      • ARP cache will age out entries
      • Bridge between L2 and L3
    • Default Gateway (Router)
      • ARP Default gateway
      • All router must be configured to forward traffic to the right gateway
      • IP segments of the destination addresses must be configured to the gateway
      • Every time a packet traversed gateway, its TTL will be decreased by 1
      • Static Routing
      • Dynamic outing
        • Routing Protocols
          • RIP
          • EIGRP
          • OSPF
          • BGP
    • Tools
      • tracert

Network Services

  • Network Topologies
    • LAN/WLAN
    • WAN
      • CAN
      • MAN
    • SAN
    • PAN

Network Address Translation

  • To communicate with the Internet
  • What it does
    • Temporarily change the private source IP to a public source IP address
  • Port Address Translation

Port Forwarding

  • Socket – IP:PORT
    • 192.168.1.1:1337

Access Control Lists

  • Allow/Deny destination or source IP addresses

DHCP

  • Client will send discover message
  • DHCP Offer
  • DHCP Binding
  • IP Helper Address

DNS Hierarchy

  • Uniform Resource Locator (URL)
    • TLD (.com, .net, .org)
    • SLD (google.com, trendmicro.com)
    • Third Level domain (www)
    • Subdomain (www.xxx.trendmicro.com)
    • Reverse DNS Lookup
      • DNS Record Types
        • A – IPv4 Record
        • AAAA – IPv6 Record
        • CNAME – Canonical Name Record (Alias)
        • MX – Mail Exchange Record
        • NS – Identifies Authoritative Name Server
        • PTR – Pointer Record
        • SRV – Service Record
        • TXT – miscellaneous use

Internal vs External DNS

  • Internal domain name system zone
  • External domain name system zone
    • Uses Internet’s DNS

Course Reference:

Pluralsight – Networking Concepts and Protocols
